Overview

Pure nickel wire is only as reliable as the system that produces it — grade, purity and documentation must line up on every spool. High conductivity pure nickel wire from DZX Alloy is drawn from 0.025 mm to 10 mm under ISO 9001 & SGS quality systems, with resistivity of 0.096 μΩ·m, thermal conductivity of 70.2 W/m·K (Ni200) and a face-centered cubic structure for ductile, repeatable forming. Four grades — N4 (≥99.9% Ni+Co), N6, Ni200 and Ni201 — are supplied with mill certificates recording the actual lot composition. Micro wire from 1 kg, standard wire from 5 kg.

Pure Nickel vs Copper and Alloy Wire

Where conductivity is the only requirement, copper wins — its resistivity of roughly 0.017 μΩ·m is far below nickel's 0.096 μΩ·m. Pure nickel wire is chosen where conductivity must survive corrosion, heat and magnetism: it keeps stable resistance in corrosive media, stays ferromagnetic to 358°C, and outlasts copper in elevated-temperature and chemical service. Nickel alloys such as CuNi trade away that conductivity for other properties, which is why specifiers pick pure nickel wire for battery tabs, electrical contacts and magnetic components rather than reaching for the alloy sheet.

Specifications

Diameters from 0.025 mm to 10 mm are drawn across our pure nickel wire products, with custom diameters and tolerances produced per drawing. Micro wire (≤0.05 mm) is ordered from 1 kg; standard wire from 5 kg.

Key Strengths

• Conductivity with staying power: resistivity 0.096 μΩ·m, thermal conductivity 70.2 W/m·K (Ni200), stable in corrosive and elevated-temperature service.

• Ferromagnetic to 358°C for motors, generators, transformers and magnetic components.

• Face-centered cubic structure for ductility, strength and consistent drawing, bending and welding.

• Grade-matched purity — N4 ≥99.9% down to Ni200/Ni201 ≥99.0-99.2% — verified by mill certificates.

• Certified supply: ISO 9001 & SGS quality systems, in-house drawing line, 300 tons per month capacity.

•

•

Technical Details

FCC Structure and the Conductivity Story

The face-centered cubic (FCC) lattice sets the property pair this page is named for: it gives the metal uniform plastic deformation — the ductility that lets wire draw, bend and weld without cracking — while the resistivity of 0.096 μΩ·m keeps resistance per unit length predictable along the spool. Thermal conductivity of 70.2 W/m·K (Ni200) carries heat away in battery and contact service. Together they make pure nickel wire the practical conductor where copper corrodes and alloys lose conductivity.

Grade Purity You Can Verify

Purity is specified per grade: N4 (≥99.9% Ni+Co) for the highest-purity service, N6 (≥99.5%) for general duty, Ni201 (≥99.0%, C ≤0.02%) for low-carbon welding-sensitive work, and Ni200 (≥99.2%, C ≤0.15%) for standard mechanical and electrical applications — all four in the pure nickel series. Every spool ships with a mill test certificate (EN 10204 3.1) recording the actual lot composition, so the purity claimed on the order is the purity on the coil.

Quality Control from Melt to Spool

Wire is drawn on our own nickel line, where every batch passes chemical composition analysis, dimensional and surface inspection before packing. Coils are wound with controlled tension so the wire pays off cleanly in automated equipment, and each coil is traceable back to its melt and lot. Batch records accompany the shipment, giving incoming inspection everything it needs to clear the material quickly.

Scale and Certification Behind the Wire

DZX Alloy has produced nickel and specialty alloy products since 2002, holds ISO 9001 & SGS certification, and counts 50+ patents and more than 2,000 industrial partners across 60+ export countries. The nickel wire line alone runs up to 300 tons per month, which keeps lead times short enough to ship standard wire in 7-15 days while holding grade, diameter and documentation consistent from melt to spool.

Pricing

Wire is priced by grade, FOB USD/kg: N4 $420-480, Ni201 $350-390, Ni200 $340-380, N6 $300-340. Micro wire (≤0.05 mm) from 1 kg; standard wire from 5 kg. Custom diameters and tight tolerances are quoted per drawing.

Chemical Composition

Mechanical & Physical Properties

Annealed wire: tensile strength ≥462 MPa, elongation ≥35%, hardness 90-120 HB. Physical constants: density 8.908 g/cm³, melting point 1435-1446°C, boiling point 2732°C, Curie point 358°C (ferromagnetic below), electrical resistivity 0.096 μΩ·m, thermal conductivity (Ni200) 70.2 W/m·K, atomic weight 58.6934.

Quality Assurance

Produced on our own nickel drawing line, every batch passes chemical composition analysis, dimensional and surface inspection before packing. Mill test certificates (EN 10204 3.1) and batch records are available with shipment, and each coil is traceable back to its melt and lot.

Applicable Standards

Ni200/Ni201: ASTM B164 (Nickel Rod, Bar and Wire). N4/N6: GB/T 21653 (Nickel and Nickel Alloy Wire and Drawn Wire Stock). Export documentation per EN 10204 3.1.

References

Material data on this page follows ASTM B164 and GB/T 21653; corrosion and application guidance references the Nickel Institute and ASM Specialty Handbook: Nickel, Cobalt, and Their Alloys; batch-level composition and geometry are verified against mill test certificates (EN 10204 3.1) and in-house inspection records.

Packaging & Delivery

Wire is wound on spools packed in carton boxes, or supplied as coils in polybags, with protective material and a safety data sheet included; each package is labeled with the product name and weight. Worldwide shipping via insured courier with tracking; freight quoted per destination. Standard production ships in 7-15 days; small in-stock quantities in 3-7 days; custom diameters or tight tolerances in 15-30 days, confirmed per drawing. Payment by L/C, T/T, Western Union or MoneyGram.

About DZX Alloy

Two decades of certified supply stand behind this wire: DZX Alloy has produced pure nickel and specialty alloy products since 2002 under ISO 9001 & SGS quality systems, with 50+ patents, over 1,000 product specifications and 2,000+ industrial partners across 60+ export countries. Drawing, finishing and inspection happen in-house in Jiangsu, China, so grade, diameter and documentation stay consistent from melt to spool — at up to 300 tons of nickel wire per month.

Submit your drawing and quantity for a confirmed quote.

FAQ

Q: What is the brand name of the pure nickel metal product?
A: The brand name is DZX Alloy.

Q: What is the model number of the pure nickel metal wire?
A: The wire is supplied in four grades — N4, N6, Ni200 (UNS N02200) and Ni201 (UNS N02201). Confirm the grade with your drawing.

Q: Where is the pure nickel metal product manufactured?
A: It is manufactured in Jiangsu, China.

Q: What is the minimum order quantity?
A: Micro wire (≤0.05 mm) from 1 kg; standard wire from 5 kg.

Q: What is the delivery time?
A: 3-7 days for small in-stock quantities, 7-15 days for standard production, 15-30 days for custom diameters or tight tolerances (per drawing).

Q: What are the payment terms?
A: L/C, T/T, Western Union and MoneyGram are accepted.

Q: What is the supply ability?
A: The nickel wire line has a capacity of up to 300 tons per month.

Q: What is the crystal structure of pure nickel wire?
A: Nickel crystallizes in a face-centered cubic (FCC) lattice, which gives the wire ductility, consistent forming and welding, and ferromagnetic behaviour up to its Curie point of 358°C.

Q: What standards apply to the wire?
A: Ni200/Ni201 follow ASTM B164; N4/N6 follow GB/T 21653. Mill test certificates are issued per EN 10204 3.1 with each shipment on request.

Q: Do you provide samples?
A: Samples are available — free 0.5 kg for N6/Ni200; charged for N4/Ni201 and refunded on the first order of 50 kg or more.
