Industrial pure nickel wire in 0.025 mm to 10 mm diameters, Ni200, Ni201, N4 and N6 grades with purity from ≥99.0% to ≥99.9%. Micro wire from 1 kg, standard from 5 kg, with EN 10204 3.1 mill certificates on export orders.
Industrial pure nickel wire is specified by medium first and grade second, because the two variables that decide service life are the corrosion profile and the operating temperature. Drawn from 0.025 mm to 10 mm in Ni200 (UNS N02200), Ni201 (UNS N02201), N4 (NP1) and N6 (NP2), the wire carries purity from ≥99.0% to ≥99.9% with carbon limits set per grade. Micro wire is ordered from 1 kg and standard wire from 5 kg, and each shipment can carry EN 10204 3.1 mill certificates for incoming inspection.
In chemical service, stainless steel wire relies on a passive oxide film that breaks down in reducing media, while nickel-plated wire depends on the integrity of its plating layer. Solid pure nickel wire carries no film and no plating: its corrosion resistance is a property of the metal itself, so cut ends, edges and weld zones keep the same resistance as the as-drawn surface. That is why industrial nickel wire keeps appearing in pumps, valves and heat exchangers where coated or filmed materials fail at the cut.
| Property | Value |
|---|---|
| Shape | Wire (solid) |
| Diameter | 0.025–10 mm |
| Temper | Soft / Hard / 1/2 Hard |
| Grades | Ni200 (UNS N02200) / Ni201 (UNS N02201) / N4 (NP1) / N6 (NP2) |
| Crystal Structure | Face-Centered Cubic (FCC) |
| Density | 8.908 g/cm³ |
| Melting Point | 1435–1446°C |
| Electrical Resistivity | 0.096 μΩ·m |
| Magnetic Behaviour | Ferromagnetic below 358°C |
Custom diameters and tolerances are produced to the drawing across the pure nickel wire range.
Corrosion resistance inherent to the metal: no film and no plating layer to wear away at a cut end or a weld zone.
Purity matched to grade: N4 at ≥99.9% Ni+Co down to Ni200 and Ni201 at ≥99.0–99.2%, with carbon limits per grade.
Melting point of 1435–1446°C for elevated-temperature service in aerospace and power generation.
Ductility and toughness: multiple slip systems let the wire draw, bend and weld without cracking.
Order terms: MOQ from 1 kg for micro wire, settled by L/C or T/T.
Multiple slip systems in the nickel lattice let the metal deform plastically instead of cracking, so the wire draws, bends and welds consistently, and components made from it survive vibration and thermal cycling. The same crystal structure sets the magnetic response, with the wire ferromagnetic up to a Curie point of 358°C wherever it sits near sensors or magnetic circuits. Annealed wire holds tensile strength of ≥462 MPa with elongation of ≥35%, which is the margin that matters on forming lines.
The wire appears in aerospace components for its oxidation resistance at elevated temperature, in power generation for heat and corrosion stability, and in chemical processing equipment for resistance to corrosive media. In each case the corrosion profile is set by the metal itself, so cut ends and weld zones behave like the as-drawn surface. For specific media, operating temperature and concentration are confirmed against the process conditions, and the mill certificate records the actual lot composition.
Purity is grade-dependent and not a single figure: N4 (≥99.9% Ni+Co) is the highest-purity designation, followed by N6 (≥99.5%), Ni201 (≥99.0%, C ≤0.02%) and Ni200 (≥99.2%, C ≤0.15%), and all four sit in the Pure Nickel Series. Specify the grade against the duty: research and vacuum service take N4, general industrial use takes N6, low-carbon welding-sensitive joints take Ni201, and standard mechanical and electrical duty takes Ni200. Applying 99.9% across the board over-specifies the price as well as the purity.
For chemical pumps, valves and heat exchangers, N6 or Ni200 balance corrosion resistance with cost. For aerospace and power generation service, N4 or N6 take the elevated-temperature duty. For electronic components and weld-sensitive assemblies, Ni201 or N4 protect joint quality where low carbon and high purity matter. Confirm grade, diameter, temper and quantity against your drawing, and the mill certificate records the actual lot composition of every spool.
| Grade | Price (USD/kg, FOB) |
|---|---|
| N4 (NP1) | 420–480 |
| Ni201 | 350–390 |
| Ni200 | 340–380 |
| N6 (NP2) | 300–340 |
Micro wire (≤0.05 mm) is quoted from 1 kg and standard wire from 5 kg. Custom diameters and tight tolerances are quoted against the drawing.
| Grade | Ni (min) | C (max) |
|---|---|---|
| N4 | 99.9% (Ni+Co) | 0.01% |
| N6 | 99.5% (Ni+Co) | 0.1% |
| Ni200 (UNS N02200) | 99.2% | 0.15% |
| Ni201 (UNS N02201) | 99.0% | 0.02% |
| Property | Value |
|---|---|
| Density | 8.908 g/cm³ |
| Melting Point | 1435–1446°C |
| Boiling Point | 2732°C |
| Curie Temperature | 358°C |
| Electrical Resistivity | 0.096 μΩ·m |
| Atomic Weight | 58.6934 |
| Thermal Conductivity (Ni200) | 70.2 W/m·K |
| Tensile Strength (annealed) | ≥462 MPa |
| Elongation | ≥35% |
| Hardness | 90–120 HB |
Every batch passes chemical composition analysis and dimensional and surface inspection before packing, and each coil is traceable to its melt and lot. Mill test certificates to EN 10204 3.1 and batch records are issued with export shipments.
Ni200 / Ni201 wire: ASTM B164 (Nickel Rod, Bar and Wire)
N4 / N6 wire: GB/T 21653 (Nickel and Nickel Alloy Wire and Drawn Wire Stock)
Export documentation: EN 10204 3.1 MTC
Standards: ASTM B164; GB/T 21653-2008; EN 10204
Industry literature: ASM Specialty Handbook: Nickel, Cobalt, and Their Alloys (ASM International); Nickel Institute corrosion and application guides
Primary sources: factory catalog, mill test certificates (EN 10204 3.1), ISO 9001 / SGS certifications
Wire is wound on spools packed in carton boxes, or supplied as coils in polybags, with protective material and a safety data sheet included, and each package is labelled with the product name and weight. Worldwide shipping with tracking, with freight quoted per destination. Standard production ships in 7–15 days, small in-stock quantities in 3–7 days, and custom diameters or tight tolerances in 15–30 days once the drawing is agreed.
DZX Alloy has supplied pure nickel and specialty alloy wire, strip and tube to industrial buyers since 2002, with over 1,000 product specifications serving 60+ export countries from the Jiangsu, China plant. ISO 9001 and SGS certified systems, in-house drawing and finishing, and a wire line producing up to 300 tons per month hold grade, diameter and documentation consistent from melt to spool across aerospace, power and chemical supply chains.
Submit your drawing and quantity for a quote.
Q: What is the brand name of the pure nickel wire?
A: The brand name is DZX Alloy.
Q: What is the model number of the pure nickel wire?
A: The model number is PNW-001, supplied in four grades: N4, N6, Ni200 (UNS N02200) and Ni201 (UNS N02201). Confirm the grade with your drawing.
Q: Where is the pure nickel wire manufactured?
A: It is manufactured in Jiangsu, China.
Q: What are the available dimensions?
A: Wire diameters range from 0.025 mm to 10 mm, and custom diameters and tolerances are produced per drawing.
Q: What purity grades are available?
A: Four grades: N4 (≥99.9% Ni+Co), N6 (≥99.5%), Ni201 (≥99.0%, C ≤0.02%) and Ni200 (≥99.2%, C ≤0.15%). The 99.9% figure applies to the N4 grade, not the full range.
Q: What is the minimum order quantity?
A: Micro wire (≤0.05 mm) from 1 kg, standard wire from 5 kg.
Q: What is the delivery time?
A: 3-7 days for small in-stock quantities, 7-15 days for standard production, and 15-30 days for custom diameters or tight tolerances (per drawing).
Q: What are the payment terms?
A: L/C, T/T, Western Union and MoneyGram are accepted.
Q: What is the supply ability?
A: The nickel wire line has a capacity of up to 300 tons per month.
Q: Do you provide samples and mill certificates?
A: Samples are available: free 0.5 kg for N6 and Ni200, charged for N4 and Ni201 and refunded on the first order of 50 kg or more. Mill test certificates (EN 10204 3.1) are issued with each shipment on request.
